开鲁盆地奈曼凹陷白垩系义县组天然碱矿地质特征及成矿条件

doi:10.12108/yxyqc.20260101

岩性油气藏 ›› 2026, Vol. 38 ›› Issue (1): 1–12.doi: 10.12108/yxyqc.20260101

• 地质勘探 •

开鲁盆地奈曼凹陷白垩系义县组天然碱矿地质特征及成矿条件

户昶昊¹^,²(), 裴家学², 杨雪², 蔡国钢², 范家铭², 李丽²

¹ 中南大学地球科学与信息物理学院, 长沙 410083
² 中国石油辽河油田公司勘探开发研究院, 辽宁盘锦 124010

收稿日期:2025-07-27 修回日期:2025-08-22 出版日期:2026-01-01 发布日期:2026-01-23
第一作者:户昶昊(1979—)，男，中南大学在读博士研究生，教授级高级工程师，主要从事油田勘探开发工作。地址：（124010）辽宁省盘锦市兴隆台区石油大街98号辽河油田公司。Email:huch6@petrochina.com.cn。
基金资助:
新型油气勘探开发国家重大科技专项“渤海湾超级盆地油气富集规律与新领域勘探技术”(2024ZD1400100);辽河油田重大科技专项“辽河探区油气伴生资源潜力及利用研究”(2024KJZX-04)

Geological characteristics and genesis of trona deposit in Cretaceous Yixian Formation of Naiman Sag, Kailu Basin

HU Changhao¹^,²(), PEI Jiaxue², YANG Xue², CAI Guogang², FAN Jiaming², LI Li²

¹ School of Geosciences and Info-physics, Central South University, Changsha 410083, China
² Research Institute of Exploration and Development， PetroChina Liaohe Oilfield Company, Panjin 124010, Liaoning, China

Received:2025-07-27 Revised:2025-08-22 Online:2026-01-01 Published:2026-01-23

摘要/Abstract

摘要：

开鲁盆地奈曼凹陷发育独特的天然碱矿，碱、盐、油共生。基于地震、测井、钻井岩心的分析测试等资料，明确了其白垩系义县组矿床的岩性组合、矿物特征、矿床特征及展布规律，从古构造、古气候、成矿物质来源及耦合关系方面探讨了天然碱矿成因及成矿模式。研究结果表明：①奈曼凹陷白垩系义县组矿床具有埋藏深、产状陡、断层发育的特征；矿层单层厚度小，隔夹层多；矿体形态近似椭圆形，南北向展布，中间厚四周薄，呈透镜状分布；发育2种沉积序列，矿床边部以苏打湖型（泥质白云岩—天然碱—泥岩）沉积序列为主，矿床中心为盐湖型（泥质白云岩—天然碱—石盐—天然碱—泥岩）沉积序列。平面上，碱—盐碱—盐呈环带状分布。②研究区矿床普遍含油，泥岩层原油赋存于细碎屑粒间孔、黏土矿物晶间孔、裂缝和干酪根中，碱、盐层油气主要赋存于矿物晶间孔缝、解理缝、包裹体、晶格缺陷中。③研究区天然碱矿为“古地貌、古气候、火山活动”三元耦合成矿模式，义县组沉积时期为封闭湖盆，周缘富钠安山岩持续向湖盆供给Na⁺；富含有机质泥岩腐烂分解产生了大量的CO₂，提高了卤水中CO₂浓度；燕山期频繁的火山活动，深部热液、幔源气通过断裂上涌，提供了大量CO₂及富含Na^＋热液；义县组沉积末期，持续的干旱气候导致湖水发生高度浓缩而达到饱和，结晶析出天然碱或石盐，经后期成岩作用形成了天然碱矿。

关键词: 天然碱矿, 古构造, 古气候, 碳源, 钠源, 油-碱-盐共生, 义县组, 白垩系, 奈曼凹陷, 开鲁盆地

Abstract:

Naiman Sag of Kailu Basin has developed unique trona deposit, which is paragenetically associated with salt and crude oil. Based on the data of seismic, logging data, drilling core laboratory analysis, the lithology assemblage, ore characteristics, deposit features and distribution patterns of the trona deposit in Cretaceous Yixian Formation were clarified. Meanwhile, the genesis and patterns of the deposit were investigated in terms of paleostructure, paleoclimate, sources of ore-forming materials, and their coupling relationships. The research results indicate that: (1) The Yixian Formation deposit of Cretaceous in Naiman Sag is characterized by deep burial, steep dip, fault development, thin individual layers and numerous interbeds. Ore body shape is approximately elliptical, with a north-south distribution direction and a lenticular distribution pattern featuring thickened centers and thinning edges. Two sedimentary sequences are developed: A soda-lake type sequence (mudstone-dolomite → trona → mudstone) dominates the deposit margins, while a saline-lake type sequence (mudstone-dolomite → trona → halite → trona → mudstone) prevails in the central zone. On the plane, trona-saline trona-salt distribute in an annular pattern. (2) The deposits are generally oil-bearing. Within mudstone layers, crude oil occurs in intergranular pores of fine clastics, inter-crystalline pores of clay minerals, fractures, and kerogen. In trona and salt layers, hydrocarbons primarily reside in mineral inter-crystalline pores and fractures, cleavage fractures, inclusions, and lattice defects. (3) The trona deposit in the study area is a ternary coupled mineral model of “paleogeomorphology-paleoclimate-volcanic activity”, the deposition of Yixian Formation constituted a closed lacustrine basin. Sodium ions (Na⁺) were continuously supplied to the basin by sodium-rich andesitic rocks in the periphery. The decomposition of organic-rich mudstone produces considerable CO₂, which increases the concentration of CO₂ in brine. The frequent volcanic activities during the Yanshan period led to the upwelling of deep-seated hydrothermal fluids and mantle-derived gas through faults, providing a large amount of CO₂ and Na⁺ -rich hydrothermal fluid. A persistent arid climate towards the end of Yixian Formation resulted in extreme concentration of the lake water, reaching saturation and precipitating trona or halite. Subsequent diagenesis formed the present trona deposit.

Key words: trona deposit, paleostructure, paleoclimate, carbon source, sodium source, co-occurrence of oil, trona and salt, Yixian Formation, Cretaceous, Naiman Sag, Kailu Basin

中图分类号:

TE121

户昶昊, 裴家学, 杨雪, 蔡国钢, 范家铭, 李丽. 开鲁盆地奈曼凹陷白垩系义县组天然碱矿地质特征及成矿条件[J]. 岩性油气藏, 2026, 38(1): 1–12.

HU Changhao, PEI Jiaxue, YANG Xue, CAI Guogang, FAN Jiaming, LI Li. Geological characteristics and genesis of trona deposit in Cretaceous Yixian Formation of Naiman Sag, Kailu Basin[J]. Lithologic Reservoirs, 2026, 38(1): 1–12.

图/表 12

图1

图2

图3

表1

图4

图5

图6

表2

图7

图8

图9

图10

参考文献 24

[1]	陈振红, 陈建立, 王九一, 等. 世界天然碱矿床资源分布、成矿因素及找矿远景[J]. 中国地质, 2023, 50(5):1399-1413.
	CHEN Zhenhong, CHEN Jianli, WANG Jiuyi, et al. Distribution and genesis of global Na-carbonate deposits and its prospecting potential[J]. Geology in China, 2023, 50(5):1399-1413.
[2]	黄华, 袁娟梅, 彭伟, 等. 江汉盆地古近系潜江组盐湖沉积特征与成藏模式[J]. 岩性油气藏, 2021, 33(2):9-16. doi: 10.12108/yxyqc.20210202
	HUANG Hua, YUAN Juanmei, PENG Wei, et al. Sedimentary characteristics and reservoir accumulation model of salt lake of Paleogene Qianjiang Formation in Jianghan Basin[J]. Lithologic Reservoirs, 2021, 33(2):9-16. doi: 10.12108/yxyqc.20210202
[3]	李文涛, 陈建立, 孙建涛. 河南桐柏县安棚一带曹庄天然碱矿芒硝矿地质特征及成因分析[J]. 矿产与地质, 2022, 36(4):759-767.
	LI Wentao, CHEN Jianli, SUN Jiantao. Geological characteristics and genesis analysis of Caozhuang natural alkali deposit and mirabilite deposit in Anpeng area,Tongbai County,Henan[J]. Mineral Resources and Geology, 2022, 36(4):759-767.
[4]	戴朝成, 钟炽涛, 刘晓东, 等. 内蒙古巴音戈壁盆地塔木素碱矿Na-碳酸盐成因模式[J]. 地球科学, 2024, 49(4):1207-1223.
	DAI Chaocheng, ZHONG Chitao, LIU Xiaodong, et al. Genetic model of Na-cabonate in Tamusu Trona Deposit,Bayinggobi Basin,Inner Mongolia[J]. Earth Science, 2024, 49(4):1207-1223.
[5]	徐少康, 石秋圆. 中国油页岩型天然碱矿床成因研究[J]. 化工矿产地质, 2023, 45(2):121-131.
	XU Shaokang, SHI Qiuyuan. Genesis study on oil shale type of natural soda deposit in China[J]. Geology of Chemical Minerals, 2023, 45(2):121-131.
[6]	向龙, 刘晓东, 刘平辉, 等. 内蒙古巴音戈壁盆地因格井坳陷下白垩统湖相热水沉积岩特征及成因[J]. 古地理学报, 2019, 21(5):709-726. doi: 10.7605/gdlxb.2019.05.048
	XIANG Long, LIU Xiaodong, LIU Pinghui, et al. Genesis and characteristics of lacustrine hydrothermal-sedimentary rock of the Lower Cretaceous in Yingejing Sag of Bayan Gebi Basin,Inner Mongolia[J]. Journal of Palaeogeography (Chinese Edition), 2019, 21(5):709-726.
[7]	周珍琦, 董清水, 厚刚福, 等. 与盐碱矿共生的油页岩形成环境及沉积演化:以桐柏吴城盆地油页岩矿床为例[J]. 吉林大学学报(地球科学版), 2006, 36(6):1001-1005.
	ZHOU Zhenqi, DONG Qingshui, HOU Gangfu, et al. The forming environment and sedimentary evolution of the oil shale intergrowthing with salt alkali mine:With the oil shale deposit of Wucheng,Tongbai Basin as an example[J]. Journal of Jilin University (Earth Science Edition), 2006, 36(6):1001-1005.
[8]	吕正祥, 廖哲渊, 李岳峰, 等. 玛湖凹陷二叠系风城组碱湖云质岩储层成岩作用[J]. 岩性油气藏, 2022, 34(5):26-37. doi: 10.12108/yxyqc.20220502
	LYU Zhengxiang, LIAO Zheyuan, LI Yuefeng, et al. Diagenesis of alkaline lacustrine dolomitic reservoirs of Permian Fengcheng Formation in Mahu Sag[J]. Lithologic Reservoirs, 2022, 34(5):26-37. doi: 10.12108/yxyqc.20220502
[9]	舒丽娟. 奈曼凹陷九佛堂组非烃流体地质意义及控制因素[J]. 岩性油气藏, 2015, 27(3):75-81.
	SHU Lijuan. Geological significance and controlling factors of nonhydrocarbon fluid of Jiufotang Formation in Naiman Sag[J]. Lithologic Reservoirs, 2015, 27(3):75-81. doi: 10.3969/j.issn.1673-8926.2015.03.011
[10]	户昶昊, 裴家学, 蔡国钢. 开鲁盆地陆东凹陷白恶系九佛堂组油气连续成藏条件[J]. 岩性油气藏, 2025, 37(3):1-12. doi: 10.12108/yxyqc.20250301
	HU Changhao, PEI Jiaxue, CAI Guogang. Continuous accumulation conditions of Cretaceous Jiufotang Formation in Ludong Depression in Kailu Basin[J]. Lithologic Reservoirs, 2025, 37(3):1-12. doi: 10.12108/yxyqc.20250301
[11]	周建民. 古碱矿中几种岩石矿物的地质意义[J]. 化工地质, 1987, 9(2):62-67.
	ZHOU Jianmin. The geological significance of several rock minerals in paleo-alkaline deposits[J]. Geology of Chemical Minerals, 1987, 9(2):62-67.
[12]	范萌萌, 卜军, 赵筱艳, 等. 鄂尔多斯盆地东南部延长组微量元素地球化学特征及环境指示意义[J]. 西北大学学报(自然科学版), 2019, 49(4):633-642.
	FAN Mengmeng, BU Jun, ZHAO Xiaoyan, et al. Geochemical characteristics and environmental implications of trace elements of Yanchang formation in southeastern Ordos Basin[J]. Journal of Northwest University (Natural Science Edition), 2019, 49(4):633-642.
[13]	王峰, 刘玄春, 邓秀芹, 等. 鄂尔多斯盆地纸坊组微量元素地球化学特征及沉积环境指示意义[J]. 沉积学报, 2017, 35(6):1265-1273.
	WANG Feng, LIU Xuanchun, DENG Xiuqin, et al. Geochemical characteristics and environmental implications of trace elements of Zhifang Formation in Ordos Basin[J]. Acta Sedimentologica Sinica, 2017, 35(6):1265-1273.
[14]	刘安, 陈林, 陈孝红, 等. 湘中坳陷泥盆系碳氧同位素特征及其古环境意义[J]. 地球科学, 2021, 46(4):1269-1281.
	LIU An, CHEN Lin, CHEN Xiaohong, et al. Carbon and oxygen isotopic characteristics of Devonian in central Hunan depression and its paleoenvironmental significance[J]. Earth Science, 2021, 46(4):1269-1281.
[15]	刘庆. 渤海湾盆地东营凹陷烃源岩碳氧同位素组成及地质意义[J]. 石油实验地质, 2017, 39(2):247-252.
	LIU Qing. Composition and geologic significance of carbon and oxygen isotopes in hydrocarbon source rocks,Dongying Sag,Bohai Bay Basin[J]. Petroleum Geology & Experiment, 2017, 39(2):247-252.
[16]	伊海生, 林金辉, 周恳恳, 等. 青藏高原北部新生代湖相碳酸盐岩碳氧同位素特征及古环境意义[J]. 古地理学报, 2007, 9(3):303-312.
	YI Haisheng, LIN Jinhui, ZHOU Kenken, et al. Carbon and oxygen isotope characteristics and palaeoenvironmental implication of the Cenozoic lacustrine carbonate rocks in northern Qinghai-Tibetan Plateau[J]. Journal of Palaeogeography (Chinese Edition), 2007, 9(3):303-312.
[17]	刘传联, 赵泉鸿, 汪品先. 湖相碳酸盐氧碳同位素的相关性与生油古湖泊类型[J]. 地球化学, 2001, 30(4):363-367.
	LIU Chuanlian, ZHAO Quanhong, WANG Pinxian. Correlation between carbon and oxygen isotopic ratios of lacustrine carbonates and types of oil-producing paleolakes[J]. Geochimica, 2001, 30(4):363-367. doi: 10.1016/0016-7037(66)90009-3
[18]	曲长胜, 邱隆伟, 杨勇强, 等. 吉木萨尔凹陷芦草沟组碳酸盐岩碳氧同位素特征及其古湖泊学意义[J]. 地质学报, 2017, 91(3):605-616.
	QU Changsheng, QIU Longwei, YANG Yongqiang, et al. Carbon and oxygen isotope compositions of carbonatic rock from Permian Lucaogou Formation in the Jimsar Sag,NW China and their paleolimnological significance[J]. Acta Geologica Sinica, 2017, 91(3):605-616.
[19]	刘海艳, 刘兴周, 蔡国刚, 等. 奈曼凹陷北部义县组—九佛堂组沉积-地球化学环境恢复及其意义[J]. 岩石矿物学杂志, 2025, 44(2):325-344.
	LIU Haiyan, LIU Xingzhou, CAI Guogang, et al. Sedimentary geochemical environment restoration of Yixian Formation and Jiufotang Formation in the northern part of Naiman sag and its signification[J]. Acta Petrologica et Mineralogica, 2025, 44(2):325-344.
[20]	JOMES B, MANNING D A C. Comparison of geochemical indices used for the interpretation of palaeoredox conditions in ancient mudstones[J]. Chemical Geology, 1994, 111(1):111-129. doi: 10.1016/0009-2541(94)90085-X
[21]	李作臣. 奈曼凹陷奈1区块CO₂地球化学特征及成因分析[J]. 长江大学学报(自然科学版), 2011, 8(6):25-28.
	LI Zuochen. Characteristics and genetic analysis of CO₂ in block Nai1 of Naiman Depression[J]. Journal of Yangtze University (Nature Science Edition), 2011, 8(6):25-28.
[22]	刘晋龙, 王国芝, 李娜, 等. 准噶尔盆地风城组硅硼钠石中包裹体特征及其地质意义[J]. 沉积与特提斯地质, 2024, 44(2):326-338.
	LIU Jinlong, WANG Guozhi, LI Na, et al. Characteristics and geological significance of inclusions in searlesite from the Fengcheng Formation in the Junggar Basin,China[J]. Sedimentary Geology and Tethyan Geology, 2024, 44(2):326-338.
[23]	张幼勋. 河南吴城天然碱矿床地质特征及成因探讨[J]. 化工地质, 1980, 2(3):66-88.
	ZHANG Youxun. Geological characteristics and genesis of the Wucheng natural soda deposit in Henan[J]. Geology of Chemical Minerals, 1980, 2(3):66-88.
[24]	李玉堂, 袁标, 刘成林, 等. 国内水硅硼钠石的首次发现[J]. 岩石矿物学杂志, 1990, 9(2):170-174.
	LI Yutang, YUAN Biao, LIU Chenglin, et al. Searlesite disco-vered for the first time in China[J]. Acta Petrologica et Minera-logica, 1990, 9(2):170-174.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

矿床名称	位置	面积/km²	埋深/m	成矿地质年代	品位/%	储量/10⁸ t
安棚	河南南阳桐柏县	10.47	1 288~2 418	古近纪	44.00	1.500 2
吴城	河南南阳桐柏县	4.66	643~974	古近纪	41.68	0.326 7
查干淖尔	内蒙古锡林郭勒盟	21.00	20~30	第四纪	27.60	5.379 1
鄂尔多斯	内蒙古鄂尔多斯市	4.00~40.00	3~8	第四纪	11.40	0.113 7
塔木素	阿拉善右旗	10.91（2区）	360~630	白垩纪	69.45	7.090 0
塔木素	阿拉善右旗	29.08（5区）	380~650	白垩纪	69.45	7.090 0
绿河	怀俄明州绿河地区	3 370.00	198~914	古近纪	75.00	560.000 0
贝帕扎里	土耳其安卡拉	8.00	250~430	古近纪	66.47~90.22	2.350 0
奈曼	内蒙古通辽市	24.00	800~3 000	白垩纪	45.94~60.93	20.770 0

样号	深度/m	Sr/Cu	MgO/ CaO	Fe₂O₃/ MnO	δ¹³C_PDB/ ‰	δ¹⁸O_PDB/ ‰	沉积时期
1	854.1	4.83	3.49	27.57	2.33	-9.21	九佛堂组沉积时期
2	854.5	5.13	1.61	27.23	2.61	-8.51
3	855.0	4.99	1.39	28.79	3.12	-7.65
4	855.5	5.25	1.55	24.81	1.94	-8.30
5	856.0	4.54	2.83	31.20	2.11	-8.14
6	856.5	2.56	1.87	48.30	2.07	-8.97
平均值		4.55	2.12	31.32	2.36	-8.46
7	1 486.5	84.54	7.64	1.00	1.92	-4.00	义县组沉积晚期（末期沉积蒸发岩）
8	1 487.1	47.84	5.35	1.55	2.48	-4.16
10	1 488.0	71.06	4.86	0.37	2.05	-3.83
11	1 488.5	40.24	1.46	3.43	4.37	-5.61
12	1 489.0	40.28	9.31	0.56	2.15	-5.12
平均值		56.79	5.72	1.38	2.59	-4.54
13	1 881.1	5.36	0.92	31.69	2.15	-15.01	义县组沉积早— 中期
14	1 882.3	1.56	1.03	35.73	0.41	-12.94
15	1 883.6	2.86	2.00	22.77	3.59	-12.52
16	1 884.5	3.40	0.57	15.05	3.19	-13.78
17	2 049.5	4.40	1.52	30.13	1.72	-17.69
18	2 050.0	3.49	2.08	20.06	1.62	-16.31
19	2 050.6	4.29	1.05	21.29	2.41	-16.50
20	2 051.2	5.92	1.15	50.44	2.51	-18.16
平均值		3.91	1.29	28.39	2.20	-15.36
